CONEC supplements SuperCon hybrid connector series
Locking is secured with a bayonet fastener, so that a time-consuming screw connection by means of a torque wrench is no longer necessary. A secure connection and the IP67 protection class are achieved by a quarter turn. It is important to note that the bayonet can only be locked when the hybrid connectors are completely plugged in. This greatly reduces the risk of failure due to connectors that are not completely plugged in or screwed together in a defined manner. The hybrid connector B23 is available with two pole number specifications, starting with a 5-pos. (4+PE) variant with a current rating of 32 A/30°C and a rated voltage of 630 V AC, where a wire cross-section up to AWG12/4.0 mm² can be used (available now). Variants will be available late summer. ▪ ds
