DIN Rail PC with
4x 2.5GbE LAN
DIN Rail PC with
Special Industrial PC / HMI
With the new DRPC-240-TGL, ICP Germany offers a modular embedded system for DIN rail use. The
standard model can be extended by a PCIe expansion box. This provides the user with a classic PCI
Express x4 slot for add-on cards. Additional add-on cards can be operated on the M.2 3042/3052/3080
and the M.2 2230 slot.
The DRPC-240-TGL is offered with Intel® CeleronTM 6305, Intel® Core-i5-1145G7E and Intel® Core-i7-1185G7E
processors. The DRPC-240 is equipped with 8 GB RAM as standard and can be expanded to a maximum of 64 GB on the
two DDR4 SO-DMM slots.
A 2.5-inch SATA 6G drive bay is available for storage media. Furthermore, the DRPC-240 offers one i225LM 2.5GbE, three i225V 2.5GbE with TSN/TCC functionality, two USB 3.2 and USB 2.0 each, as well as two RS-232 and RS-422/485 each with 2.5 kV isolation, six digital inputs, six digital outputs, one HDMI with 3840 x 2160 resolution and one display port with 4096 x 2304 pixels resolution.
The system is designed for fanless use and can be expanded with an external fan module if needed. The DRPC-240 can be supplied with an input voltage from 12 V to 24 VDC via the three-pin terminal block.
On customer request, ICP delivers the DRPC-240-TGL pre-assembled and with integrated operating system as a ready-to-use system. ▪ ds
A 2.5-inch SATA 6G drive bay is available for storage media. Furthermore, the DRPC-240 offers one i225LM 2.5GbE, three i225V 2.5GbE with TSN/TCC functionality, two USB 3.2 and USB 2.0 each, as well as two RS-232 and RS-422/485 each with 2.5 kV isolation, six digital inputs, six digital outputs, one HDMI with 3840 x 2160 resolution and one display port with 4096 x 2304 pixels resolution.
The system is designed for fanless use and can be expanded with an external fan module if needed. The DRPC-240 can be supplied with an input voltage from 12 V to 24 VDC via the three-pin terminal block.
On customer request, ICP delivers the DRPC-240-TGL pre-assembled and with integrated operating system as a ready-to-use system. ▪ ds
