Small power connectors for more efficiency in device production

Insulation bodies with shield sheet and O-ring offer the great advantage of being fully automated and processed in the THR reflow soldering process, which significantly increases the efficiency of device production in the electronics sector and reduces production costs.
The new connectors are always supplied with a foil or cap for pick and place application and, upon request, in tape and reel packaging. In addition, corresponding protective caps are now available for the M12 L-coded connectors. The shield connection between the insulating body and the flange housing is made using a spring-loaded shield sheet which automatically compensates for tolerances and micro-movements. The contact is made securely with 2 contact zones. The axial M12 L-coded connectors require approximately 50 percent less installation space compared to a 7/8-inch connector.

Due to the high current carrying capacity of up to 16 A, they are also able to ensure the power supply of devices through a miniaturized interface. This is necessary because electrical drive technology devices are also becoming more and more compact. Thus, signals, data and power can now be transmitted consistently with the help of the M12x1 connector system and this with shielded or non-shielded cables. The new M12x1 L-coding is standardized according to IEC 61076-2-111. The L-coded insulating bodies with O-ring are available as male and female version, each in 4-positions and in 4-positions with FE. Suitable housings are available for front and rear panel mounting, with width flats providing anti-rotation protection in the housing, if required. The new protective caps for the M12 L-coded version offer optimum protection against contamination in harsh environments and thus always ensure an operational interface. All variants meet the IP67 degree of protection in mated and mounted condition. ▪ ds
