The runtime of the newly developed visualization software Simatic WinCC Unified in the TIA (Totally Integrated Automation) Portal is based on native Web technologies such as HTML5, SVG and JavaScript. The high scalability of the newly platform enables end-to-end solutions, from machine-level applications all the way to the SCADA system.

Software for the visualization with open API interfaces

When designing the system, Siemens focused on the overall openness. For this purpose, open API interfaces such as TIA Portal Openness were implemented which enable automated engineering, on the one hand, and considerably simplify data exchange during operation, on the other hand. For this, an ODK (Open Development Kit) and an OpenPipe interface are available to the user, as well as the option to integrate other applications into the user interface of WinCC Unified.
Engineering is consistently integrated in the TIA Portal, the engineering framework with modern programming languages and seamless data flow. Components created once can be re-used on all platforms, whether on the operator panel, on the PC or as apps in the Cloud- and Edge environment. WinCC Unified Runtime can be accessed via all modern Internet browsers without the installation of separate plugins. In the first version, WinCC Unified is available for Panel- and PC-based solutions. The use of WinCC Unified in the Edge- and Cloud environment will be possible in a later delivery stage.
